Apache Kafka: Comprehensive Guide

Learning Goals

By the end of this guide, you will understand:

  • What Kafka is and why it's used for distributed streaming
  • Kafka architecture: brokers, topics, partitions, and replicas
  • Producer and consumer concepts with acknowledgment levels
  • Kafka cluster configuration (static and dynamic)
  • Operational procedures: creating topics, producing/consuming messages, managing offsets
  • Partition reassignment for scaling operations
  • Troubleshooting common Kafka issues

1. What is Apache Kafka?

Apache Kafka is a distributed streaming platform built for:

  • High-throughput: Handle millions of messages per second
  • Low-latency: Sub-second message delivery
  • Scalability: Distribute data across multiple brokers
  • Durability: Persist messages to disk with configurable retention
  • Ecosystem: Large ecosystem of tools and integrations

Key Characteristics

FeatureBenefit
Publish-Subscribe ModelProducers and consumers are decoupled
Distributed ArchitectureFault tolerance through replication
Persistent StorageMessages stored on disk, not lost on restart
Partitioned TopicsParallel processing across multiple consumers
Configurable RetentionTime-based or size-based message cleanup

Use Cases

  • Real-time data pipelines
  • Event streaming applications
  • Log aggregation
  • Metrics collection
  • Stream processing
  • Microservices messaging

2. Kafka Architecture: Visual Overview

Kafka Architecture

High-Level Components:

  • Zookeeper/KRaft: Cluster coordination and metadata management
  • Brokers: Core Kafka servers storing and serving messages
  • Topics: Logical message channels (e.g., orders, user-events)
  • Partitions: Parallel streams within topics for scaling
  • Producers: Applications that send messages
  • Consumers: Applications that read messages
  • Consumer Groups: Groups of consumers coordinating consumption

3. Core Kafka Concepts

3.1: Broker

The core of Kafka — servers that store messages and serve requests.

Key Points:

  • Each broker has a unique broker.id
  • Single broker or clustered setup (minimum 3 for production)
  • Each broker can hold multiple topics and partitions
  • Brokers communicate with Zookeeper/KRaft for coordination

3.2: Topic

Logical channel where messages are published.

Characteristics:

  • Unique name (e.g., user-events, orders)
  • Messages are immutable (write-once, read-many)
  • Updated data sent as new message (not overwritten)
  • Supported by multiple producers and consumers simultaneously
  • Data persists based on retention policy

3.3: Partition

Physical subdivision of a topic for parallel processing.

Key Details:

  • Minimum: 1 partition per topic
  • Each message within a partition assigned an offset (unique ID)
  • Offsets start at 0 and increment sequentially
  • Consumers read messages in order within a partition
  • Parallelism: Number of consumers in a group limited by number of partitions
Topic: user-events
├── Partition 0: [msg0 (offset 0), msg3 (offset 1), msg6 (offset 2), ...]
├── Partition 1: [msg1 (offset 0), msg4 (offset 1), msg7 (offset 2), ...]
└── Partition 2: [msg2 (offset 0), msg5 (offset 1), msg8 (offset 2), ...]

3.4: Replica

Copy of partition for fault tolerance.

Replica Roles:

  • Leader: Handles all reads and writes for the partition
  • Follower: Replicates data from leader asynchronously
  • Minimum: 1 replica (typically 3 for production)

Replication Factor = 3:

Partition 0 Leader: Broker 1
Partition 0 Replicas: Brokers 2, 3
(If Broker 1 fails, Broker 2 becomes new leader)

3.5: In-Sync Replicas (ISR)

Replicas that are fully caught up with the leader.

Definition:

  • Always includes the partition leader
  • Followers are ISR only if they haven't fallen behind
  • If follower stops replicating, removed from ISR
  • Affects acknowledgment (acks=all) behavior
Leader Offset: 1000
Follower 1 Offset: 1000 ✅ (In ISR)
Follower 2 Offset: 995 ❌ (Lagging, not in ISR)

3.6: Producer

Application that publishes messages to topics.

Key Operations:

Producer → [Partitioner] → Partition Selection → Broker
         ↓
       Acknowledgment (acks setting)

Partitioner Strategy (default):

  • If key provided: Hash(key) % num_partitions
  • If no key: Round-robin across partitions

3.7: Consumer

Application that subscribes to topics and processes messages.

Consumption Model:

  • Reads messages in partition order (within partition only)
  • Tracks position via offset (cursor)
  • Can read from specific offset or from beginning/end

Consumer Group:

  • Group of consumers for the same topic
  • Each partition assigned to one consumer in group
  • Enables parallel processing: 3 partitions → 3 consumers max per group
  • Different groups read independently from same topic

3.8: Acknowledgment (ACK) Settings

Controls durability vs. latency tradeoff for producers.

ACK ValueBehaviorData Loss RiskLatency
acks=0Producer doesn't wait for broker response❌ High (data may be lost)✅ Lowest
acks=1Waits only for leader to write to local log⚠️ Medium (if leader fails before replication)⚠️ Medium
acks=allWaits for all in-sync replicas to confirm✅ Very Low (all replicas have data)❌ Highest

Production Recommendation: acks=all for critical data

4. Kafka Cluster Coordination

4.1: Zookeeper vs. KRaft

Zookeeper (Legacy):

  • Separate metadata store
  • Leader-follower election for brokers
  • Minimum 3 nodes for quorum

KRaft (Modern):

  • Metadata management built into Kafka
  • Simpler architecture, no external coordinator
  • Quorum calculation: QN = (N + 1) / 2

Quorum Requirement:

3 Zookeeper nodes: Tolerates 1 node failure ✅
5 Zookeeper nodes: Tolerates 2 node failures ✅

5. Kafka Configuration: Static vs. Dynamic

5.1: Static Configuration

Located at: [KAFKA_DIR]/config/server.properties

Must restart broker to apply changes.

Key Settings:

# Broker Identity
broker.id=0

# Network
listeners=PLAINTEXT://[IP]:9092
advertised.listeners=PLAINTEXT://[IP]:9092

# Performance
num.network.threads=32
num.io.threads=32

# Storage
log.dirs=/data/kafka-logs-1,/data/kafka-logs-2,/data/kafka-logs-3
log.retention.hours=168
log.segment.bytes=524288000

# Replication
default.replication.factor=3
num.partitions=18

# Zookeeper Coordination
zookeeper.connect=[ZK-IP]:2181,[ZK-IP]:2181,[ZK-IP]:2181

5.2: Dynamic Configuration

Applied without broker restart using CLI tools.

Tool: kafka-configs.sh

# Change a config
/opt/kafka/bin/kafka-configs.sh --alter \
  --bootstrap-server broker-ip:9092 \
  --entity-type brokers \
  --entity-default \
  --add-config log.segment.bytes=524288000

# View current dynamic configs
/opt/kafka/bin/kafka-configs.sh --describe \
  --bootstrap-server broker-ip:9092 \
  --entity-type brokers

Advantages:

  • No broker downtime
  • Changes persist across restarts (stored in Zookeeper/KRaft)
  • Ideal for adjusting retention, segment sizes, etc.

6. Producer and Consumer Operations

6.1: Producer Workflow

Producer-Consumer Flow

Steps:

  1. Producer creates message with optional key and value
  2. Partitioner determines target partition (via key or round-robin)
  3. Message sent to broker leader for that partition
  4. Leader writes to local log
  5. Replicas replicate from leader
  6. Acknowledgment sent based on acks setting
  7. Producer receives confirmation or error

6.2: Consumer Workflow

Consumer → Query Broker for Next Offset → Fetch Messages → Process
   ↓
   Commit Offset (mark message as consumed)

Offset Management:

  • Automatic: Consumer automatically commits after processing
  • Manual: Application commits after successful processing
  • Reset: Ability to replay messages by resetting offset

7. Replication & Durability

Replication Architecture

7.1: Replication Process

Scenario: Topic with replication factor 3

Message arrives at Partition 0, Leader on Broker 1:
1. Write to Leader (Broker 1) ✅
2. Broker 2 (follower) fetches and replicates ✅
3. Broker 3 (follower) fetches and replicates ✅
4. All three brokers now have identical data

7.2: Failure Scenarios

Leader Broker Fails:

  • Zookeeper/KRaft detects failure
  • New leader elected from ISR (Brokers 2 or 3)
  • Producer/consumer automatically reconnect
  • Messages not lost (data on surviving brokers)

Follower Broker Fails:

  • Removed from ISR temporarily
  • acks=all producers still succeed (leader + other replicas)
  • Follower rejoins ISR when caught up

Multiple Brokers Fail:

  • Risk depends on replication factor
  • RF=1: Single failure = data loss
  • RF=3: Can tolerate 2 failures

8. Topic Management

8.1: Create Topic

# With Zookeeper
kafka-topics.sh --create \
  --zookeeper zk-ip:2181 \
  --topic orders \
  --replication-factor 3 \
  --partitions 18

# With KRaft (no Zookeeper)
kafka-topics.sh --create \
  --bootstrap-server broker-ip:9092 \
  --topic orders \
  --replication-factor 3 \
  --partitions 18

8.2: List Topics

kafka-topics.sh --list --bootstrap-server broker-ip:9092

8.3: Describe Topic

# Show partition layout and replicas
kafka-topics.sh --describe \
  --bootstrap-server broker-ip:9092 \
  --topic orders

# Output:
# Topic: orders  Partitions: 18  Replicas: 3
# Partition  Leader  Replicas         ISR
# 0          1       [1, 2, 3]        [1, 2, 3]
# 1          2       [2, 3, 4]        [2, 3, 4]
# ...

8.4: Modify Topic (Dynamic)

# Change retention to 1 hour
kafka-configs.sh --alter \
  --bootstrap-server broker-ip:9092 \
  --entity-type topics \
  --entity-name orders \
  --add-config retention.ms=3600000

9. Producing Messages

9.1: Console Producer

# Interactive: type messages manually
kafka-console-producer.sh \
  --topic orders \
  --bootstrap-server broker-ip:9092

# Type messages (Ctrl+C to exit):
# > order1,100,USD
# > order2,200,EUR

9.2: Performance Test Producer

# Produce 1000 messages at 100 msg/s
kafka-producer-perf-test.sh \
  --topic orders \
  --num-records 1000 \
  --record-size 1024 \
  --throughput 100 \
  --producer-props \
    bootstrap.servers=broker-ip:9092 \
    acks=all

# Output:
# 1000 records sent, 98.52 records/sec
# Avg latency: 10.23 ms
# Max latency: 145 ms

9.3: Producer with Key

# Messages with same key go to same partition
kafka-console-producer.sh \
  --topic orders \
  --bootstrap-server broker-ip:9092 \
  --property "parse.key=true" \
  --property "key.separator=:"

# Type:
# > user123:order1,100
# > user123:order2,200  # Same partition (user123 is key)
# > user456:order3,150  # Different partition (user456 is key)

10. Consuming Messages

10.1: Console Consumer

# Read from beginning
kafka-console-consumer.sh \
  --topic orders \
  --bootstrap-server broker-ip:9092 \
  --from-beginning

# Read new messages only
kafka-console-consumer.sh \
  --topic orders \
  --bootstrap-server broker-ip:9092

10.2: Consumer Group

# Consume as part of group "order-processors"
kafka-console-consumer.sh \
  --topic orders \
  --bootstrap-server broker-ip:9092 \
  --group order-processors \
  --from-beginning

# Different groups can read same topic independently
kafka-console-consumer.sh \
  --topic orders \
  --bootstrap-server broker-ip:9092 \
  --group analytics-group \
  --from-beginning

10.3: List Consumer Groups

kafka-consumer-groups.sh \
  --list \
  --bootstrap-server broker-ip:9092

# Output:
# order-processors
# analytics-group
# payment-processors

11. Consumer Offset Management

11.1: Check Offset Lag

# Show offsets and lag for a consumer group
kafka-consumer-groups.sh \
  --describe \
  --group order-processors \
  --bootstrap-server broker-ip:9092

# Output:
# TOPIC      PARTITION  CURRENT-OFFSET  LOG-END-OFFSET  LAG
# orders     0          1050            1100            50
# orders     1          2020            2050            30
# orders     2          3005            3008            3
# Total LAG: 83 messages behind

Interpretation:

  • CURRENT-OFFSET: Where this consumer group is at
  • LOG-END-OFFSET: Latest message in partition
  • LAG: Messages consumer hasn't processed yet

11.2: Reset Offset to Earliest

# Reset to beginning for all topics
kafka-consumer-groups.sh \
  --reset-offsets \
  --to-earliest \
  --group order-processors \
  --all-topics \
  --execute

# Reset for specific topic
kafka-consumer-groups.sh \
  --reset-offsets \
  --to-earliest \
  --group order-processors \
  --topic orders \
  --execute

11.3: Reset Offset to Latest

# Skip all current messages, start from latest
kafka-consumer-groups.sh \
  --reset-offsets \
  --to-latest \
  --group order-processors \
  --topic orders \
  --execute

11.4: Reset to Specific Offset

# Back up current offsets
kafka-consumer-groups.sh \
  --export \
  --group order-processors \
  --bootstrap-server broker-ip:9092 \
  --reset-offsets \
  --to-current \
  --dry-run > backup.txt

# Restore from backup
kafka-consumer-groups.sh \
  --reset-offsets \
  --from-file backup.txt \
  --group order-processors \
  --bootstrap-server broker-ip:9092 \
  --execute

12. Partition Reassignment

Use Case: Scale Up or Down

When adding/removing brokers, redistribute partitions for balanced load.

12.1: Scale-Up Example (3 → 5 brokers)

# Step 1: Create topic list
cat > topics.json <<EOF
{
  "version": 1,
  "topics": [
    {"topic": "orders"},
    {"topic": "payments"}
  ]
}
EOF

# Step 2: Generate proposed assignment
kafka-reassign-partitions.sh \
  --zookeeper zk-ip:2181 \
  --generate \
  --topics-to-move-json-file topics.json \
  --broker-list 0,1,2,3,4 \
  > reassign.json

# Step 3: Review proposed assignment in reassign.json

# Step 4: Execute reassignment
kafka-reassign-partitions.sh \
  --zookeeper zk-ip:2181 \
  --execute \
  --reassignment-json-file reassign.json

# Step 5: Monitor progress
kafka-reassign-partitions.sh \
  --zookeeper zk-ip:2181 \
  --verify \
  --reassignment-json-file reassign.json

12.2: Fix Leader Imbalance

# After reassignment, elect preferred replicas
kafka-preferred-replica-election.sh \
  --bootstrap-server broker-ip:9092

# This ensures partition leaders are distributed evenly

13. Troubleshooting

13.1: Check Broker Connectivity

# Verify broker is reachable
telnet broker-ip 9092

# Or using nc
nc -zv broker-ip 9092

# Check broker status
sudo systemctl status kafka

13.2: Consumer Lag

# If lag is high, consumers are slow
kafka-consumer-groups.sh \
  --describe \
  --group order-processors \
  --bootstrap-server broker-ip:9092

# Solutions:
# - Increase num.consumer.instances (up to partition count)
# - Optimize consumer processing speed
# - Increase partition count and rebalance

13.3: Producer Failures

# Check if messages are being persisted
# Review logs on broker:
tail -f /var/log/kafka/server.log

# Common issues:
# - Broker not responding (check connectivity)
# - Authentication/authorization issues
# - Topic doesn't exist (auto-create disabled)

13.4: Disk Space Issues

# Purge messages by setting retention to 1 second temporarily
kafka-configs.sh \
  --alter \
  --bootstrap-server broker-ip:9092 \
  --entity-type topics \
  --entity-name orders \
  --add-config retention.ms=1000

# Wait 10 seconds for cleanup

# Restore retention
kafka-configs.sh \
  --alter \
  --bootstrap-server broker-ip:9092 \
  --entity-type topics \
  --entity-name orders \
  --add-config retention.ms=604800000

14. Additional Resources

Next Steps

  1. Read kafka/WORKSHOP.md for hands-on Docker lab
  2. Practice creating topics, producing, and consuming locally
  3. Monitor lag and rebalancing in your Kafka cluster
  4. Optimize retention, partitions, and replication settings based on your workload
